| Model Name | Size | Nozzle (mm) | MOQ (pcs) |
| SEW-BVFH-148 | 1/4" | 8 | 1000 |
| SEW-BVFH-388 | 3/8" | 8 | 1000 |
| SEW-BVFH-128 | 1/2" | 8 | 1000 |
| SEW-BVFH-1410 | 1/4" | 10 | 1000 |
| SEW-BVFH-3810 | 3/8" | 10 | 1000 |
| SEW-BVFH-1210 | 1/2" | 10 | 1000 |
Material:
1) Body, Ball & Stem: Free cutting Brass CZ121 or any other customized materials.
2) Handle Locking Bolt & Nut: M.S, S.S or any other customized materials.
3) O-Ring: PTFE or any other customized materials.
4) Handle:
i) Butterfly: Aluminium or any other customized materials.
ii) T-Handle: Aluminium or any other customized materials.
iii) Lever Handle: Cast Aluminum Long Handle, Forged Iron Long Handle or Forged Steel Handle with PVC coating.
Thread: NPT, BSP or any other customized threads.
Temprature: -22°F to +302°F (-30°C to +150°C).
Pressure (PN): Max 40bar up to 95°C & Max 25bar at 150°C.
Finishing: Nickel / Chrome / any other customized finishing. (Available for Body & Ball).
Features:
• Forged Brass 2 piece body.
• Threads according to ISO 228/1.
• Also available, Brass according to DIN 17660.
Application:
• Applicable for Gas, Oil & Water medium.
